Network Cable Tester..

Bahan2 yang digunakan:

4 x LED

1 x Switch Toggle ...

2 x Perintang (Transistor)

8 x Wire Copper (amik dari cable CAT 6)

1 x Faceplate

1 x Base box

2 x Modular Jack

Type of Equitment In Network Design

-Patch Panel

-Modeler Jack

-RJ45

-Face Plate

-Cable Manager

-Racle Cabling

-Switch

-Router

-Firewall

-Wireless

-Computer


Tool

-Puncher

-Crimping Tool

-Network Tester

-Cable Stripper

-Player

-Sesaw

-Knife

-Pen Labeling

-Stiker



Type of Media

-CAT 3=16Mbp/16Mbps

-CAT 5=100 Mhz/100Mbp

-CAT 5e=100Mhz/100/1GB

-CAT 6=150Mhz/1GBps

-CAT 6e=150/1GB/10GB

-CAT 7=250/500Mhz/10GB

kaler-kalerful Of Cable~~~(^__^)

                                                      Straight Thru Cable

-White Orange
-Orange
-White Green
-Blue
-White Blue
-Green
-White Brown
-Brown

                                                       Cross Cable

-White Green
-Green
-White Orange
-White Blue
-Orange
-White Brown
-Brown

Basic Network Cabling

-Menyambung apa2 jenis devise menggunakan cabling.

Type of Cable

1)Twisted Pair Cable (untuk networking)

-UTP(Unshielded Twisted Pair)

-STP(Shielded Twisted Pair)
2)Coqxial Cable(cctv,area tv)
3)Fibre Optik


Type of  UTP Cable

-CAT 3
-CAT 4
-CAT5
-CAT 5e
-CAT 6
-CAT 6e
-CAT 7

Twisted Pair

-4 Pair
-8 Cable
-Straight Thru Cable
-Cross Cable
-Devise yang sama

Security Attack

-Antivirus
-Firewall
-Encryption
-Ip Segmentation
-Ip Security(ip sec)


Hashing
-Base 64
-MDS

Symmetric
-AES
-DES

Asymmetric
-RSA(guna 3 key)
-Another RSA

Basic Data Communication

-Sender
-Receiver
-Medium@Media
-Protokol
-Masegge

Encryption

-Proses tranformasi menggunakan key@cipher untuk tukar
perkataan kepada bahasa yang tidak difahami dipanggil nama ciphertext.

Plaintext(cth)

A(D),B(E),C(F),D(G),E(I),F(I),G(J),H(K),I(L),J(M),K(N),L(O)M(P),N(Q),O(R),P(S),Q(T)

R(U),S(V),T(W),U(X)V(Y),W(Z),X(A),Y(B),Z(C).


JENIS-JENIS CIPER
-PGP(Preety Good Pryvacy)
-CEASER CIPER
-3DES/DES
-MDS HAST

CEASER CIPER(diguna pada masa kini)
